Brand

SINOTRUK

Product name

HOWO water sprinkler truck

Engine model

WD615.69  336HP  247KW Euro2

Engine type

water-cooled,four strokes,6 cylinders in line with water cooling,turbocharged and inter-cooling, directly injection

Engine exhaust(ml)

9726

Chassis

6x4 right hand drive

Tank volume(L)

20000

Overall dimension(mm)

10000x2500x3400

Gross weight(kg)

31765

Rated loading(kg)

20000

Curb weight(kg)

11570

Passenger in cab

2

Wheelbase (mm)

4325+1350mm

Gear Box

HW19710 10 speed forward 2 reverse

Front axle/Rear axle

7tonss/16tons

Cab

HW76 a row and a half deluxe cab(with sleeping berth), allowable 3 passengers

Braking system

Air cut brake

Tank material

Carbon steel

Tank thickness(mm)

5
