Description

Parameter value

Operating weight

2780Kg

Bucket capacity

0.06m³

Engine

Model

Kubota/D1105 /EU Stage V

No. of cylinders

3

Output power

15.4 kW (20.9 hp) / 2400 rpm

torque/speed

70.3 N.m/1600 rpm

Displacement

1123 cm³

Hydraulic system

Travel speed (low - high)

2.2- 3.1km/h

Gradeability

30°

Oil Capacity

Fuel tank capacity

33L

Hydraulic tank capacity

22L

Engine oil capacity

5.1L

Working scope

Boom deflflection distance (left/right)

610/585 mm

Max. digging height

4390mm

Max. dumping height

3120mm

Max. digging depth

2800mm

Max. vertical wall digging depth

2310mm

Max. digging radius

4750mm

Min. swing radius

1980mm
