Model

Unit

XE470D

Operating weight

Kg

46900

Bucket capacity

m³

2.2-2.5

Engine

Model engine

/

QSM11-335

Injection

/

√

Four strokes

/

√

Water cooling

/

√

Turbo-charging

/

√

No. of cylinders

/

6

Rated power/speed

kw/rpm

274/1800

Maximum torque/speed

N.m/rpm

1790/1400

Displacement

L

11

Main performance

Travel speed

km/h

5.4/3.2

Swing speed

r/min

9

Gradeability

°

35

Ground pressure

kPa

83

Bucket digging force

kN

287

Arm digging force

kN

221

Maximum tractive force

kN

338

Hydraulic system

Rated flow of main pump

L/min

2×360

Travel system pressure

MPa

34.3

Swing system pressure

MPa

28.4

Pilot system pressure

MPa

3.9

Oil Capacity

Fuel tank capacity

L

725

Hydraulic tank capacity

L

430

Engine oil capacity

L

38

Appearance size

Overall length

mm

11670

Overall width

mm

3582

Overall height

mm

3890

Width of platform

mm

2995

Total width of chassis

mm

3582

Track shoe width

mm

600

Wheel base of crawler

mm

4292

Track gauge

mm

2750

Counterweight clearance

mm

1324

Min. ground clearance

mm

519

Working range

Max. digging height

mm

9855

Max. dumping height

mm

6890

Max. digging depth

mm

7000

Max. vertical wall digging depth

mm

4500
