Classificatory

Item

Unit

Parameter

Outline dimension

Overall length

mm

12000

Overall width

mm

2500

Overall height

mm

3380

Mass

Total mass in travel state

kg

31000

Axle load

Front Axle

kg

6440

Rear Axle

kg

24600

Travel performance

Travel speed

Max. travel speed

km/h

75

Turning diameter

Min. turning diameter

m

22

Min. ground clearance

mm

260

Approach angle

(°)

16

Departure angle

(°)

13

Braking distance (at speed of 30km/h)

m

10

Max. grade-ability

%

30

Fuel consumption for 100km

L

37

Power

Engine rated output

kW/(r/min.)

206/2200

Engine rated torque

N.m/(r/min.)

1112/1400

Engine rated speed

rpm.

2200
