Item

Dimensions

Overall length

15600×3000×3850

Lifting Performance

Max.total rated lifting capactiy

100

Min.rated working radius

3

At counterweight

4200

At auxilary winch

4590

Base boom

3450(4m×88t)

Full-extended boom

1925(2.4m×8.3t)

Full-extended boom+Jib

708(25.8×2.8t)

Longitudinal distance

7.56

Lateral distance

7.6

Base boom

13.5

Full-extended boom

50.9

Full-extended boom+Jib

70.4

Base boom

13.5

Full-extended boom

51

Full-extended boom+Jib

51+18.1+4

Working speed

Jib offset

0、15、32

3Boom raising

75

Full-extending

160

Max.swing speed

2

Outrigger beam extending/Retracting

25/15

Outrigger jack extending/Retracting

45/25

Main hoist mechanism with empty load

105

Auxiliary hoist mechanism with empty load

104
