Cabin

HW 76 Standard Cab, Left hand drive, one sleeper. A/C

With two bunks, 70° hydraulically tillable to the front as attached photo for ref.

Weight in KGS

Tare Weight

11950

Loading Capacity

20000

Front axles loading capacity

HF9   1x9000

Rear axles loading capacity

ST16  2x16000

Max. driving speed(km/h)

75

Engine

Brand

Sinotruk

Model

WP12.400.E201

Type

4-stroke direct injection ,  6-cylinder in-line with water cooling, turbo-charging and inter-cooling

Horse Power(HP)

400HP

Emission standard

Euro Ⅱ

Gearbox

HW19710,  10 Forwards gear & 2 reverse

Clutch

Reinforced diaphragm clutch, diameter 430mm

Steering Gear

ZF 8098, power steering, hydraulic steering with power assistance

Fuel tank (L)

300

Tire

12R22.5 radial steel tire 11 Pieces including one spare

Brakes

Service brake: dual circuit compressed air brake

Parking brake :(emergency brake): spring energy, compressed air operating on rear wheels

Auxiliary brake: engine exhaust valve brake

Tank

20CBM, tank thickness is 4mm, seal is 5mm.

Equipped with front(rear, side)sprinkler(sprinkler width>14m).

Equipped with pump(suction lift>6m)

Equipped with fire valve, water valve, and filter gauze.

Equipped with rear working platform with water cannon.

Rubber Padding between the tanker & chassis.
