Items

Descriptions

Specifications and Types

Drive Type

4*2

Gross Vehicle Weight(kg)

11495

Curb Weight (kg)

6000

Overall Dimensions L*W*H(mm)

7200×2495×3040

Engine

Engine Brand

CUMMINS

Fuel Type

Diesel

Power

125kw/170HP

Emission Standard

Euro III

Displacement(ml)

5900

Engine Type

4 cylinders in line, water cooling, turbo-charged diesel engine, inter-cooling

Chassis

Chassis Brand

Howo

Cab

Flat roof, one row with single sleeper

Tire No.

6+1

Tire Specification

9.00-20 Nylon tire

Wheelbase (mm)

3950

Axle No.

2

Gear Box

8 speed forward with 1 reverse, manual

Brake

Air brake

Steering Wheel

Left Hand Drive with power-assisted

Crane and outrigger

Crane

Kunckle boom crane

Max lifting capacity(tons)

5

Max lifting height(m)

10.8

Max working radius(m)

8.25

Boom No.

3 section

Outrigger No.

2 pcs front outrigger, rear outrigger is optional

Rotation angle

360 degree full rotation

Clip

Block Clip Size(mm)

1000x1000x1000

Block Operation Type

Hydraulic

Box

Box Size(mm)

4000x2300x550
