Products Technical Specification

Type

water spraying truck

Brand

Howo 4*2

Cab

With A/C, on bed

Vehicle Description

Overall dimensions（mm）

8350x2550x3200

Curb weight(vehicle) (kg)

10570

Loading capacity (kg)

18000

Max speed (Km/h)

89

Engine

Mode

MC07H.33-60

Type

Diesel, 6-cylinder in line with water cooling,

turbo-charging

Max. power

240(KW) /325hp

Rotated speed

2300(rpm)

Displacement(ML)

6200

Company of engine

Howo

Chassis

Wheel base

4500

Operation control system

Power Steering

Electric system

24V

Tyres

10.00R20 18PR

Tanker

Capacity of tank body

11.00 Litres

Dimensions（mm）

4600X2350X1560

Material of tank body

Q235B Carbon steel

Install water pump

Side outlet and inlet, can fill water into tank body by water pump

With rear water spraying monitor.

Multifunction pesticide sprayer truck

With one manhole on the top of tank body.

Sprayer Machine

valid distance

40 meters, no wind condition.

Operation mode

Manual and remote control

Fan motor

Customize

Painting: three layer painting, anit-rust, bottom painting. Outside painting.
