SHACMAN X3000 8X4 Lorry Truck-Products Center-HOWO SINOTRUCK

Parameter

Specification

Vehicle Model

SHACMAN X3000 8×4 Lorry Truck

Vehicle Type

Cargo Truck / Lorry Truck

Drive Type

8×4

Cabin

X3000 High Roof Cabin With Sleeper

Driving Type

Left-hand Drive / Right-hand Drive

Seat Configuration

2 Seats + 1 Sleeper

Cabin Equipment

Air Conditioner, Air Suspension Seat, Electric Window, Central Lock

Engine Brand

WEICHAI / CUMMINS

Engine Model

WP13.550E501

Horsepower

550 HP

Emission Standard

Euro II / Euro III / Euro V

Displacement

12.54 L

Maximum Torque

2550 N·m

Transmission Brand

FAST

Transmission Model

12JSDX240TA

Gearbox

12 Forward & 2 Reverse

Clutch

430 mm Diaphragm Clutch

Front Axle

9.5T MAN Axle ×2

Rear Axle

16T MAN Double Reduction Axle ×2

Axle Ratio

4.769 / 5.262 Optional

Steering System

ZF Hydraulic Steering

Brake System

Dual Circuit Air Brake

Parking Brake

Spring Energy Brake

ABS

Optional

Suspension

Heavy-duty Multi-leaf Spring

Fuel Tank Capacity

500 L

Tire Specification

12.00R20 / 315/80R22.5

Number Of Tires

12 + 1 Spare Tire

Wheelbase

1800 + 4575 + 1400 mm

Overall Dimension

11900 × 2550 × 3650 mm

Cargo Body Length

9600 mm

Cargo Body Width

2450 mm

Cargo Body Height

2400 mm

Cargo Body Material

High-strength Steel

Side Wall Type

Fence Type / Stake Type

Cargo Volume

55–65 m³

GVW

41000 kg

Curb Weight

14500 kg

Payload Capacity

50–60 Tons

Maximum Speed

95 km/h

Minimum Turning Radius

12 m

Ground Clearance

314 mm

Application

Long-distance Logistics / Industrial Cargo / Agricultural Transport / Heavy-duty Freight

Optional Configuration

Customized Configuration Supported

SHACMAN X3000 8X4 Lorry Truck
