Basic paramete

Vehicle code

BJ4259SMFKB-RD

Vehicle type

Tractor

Platform

EST

Drive form

6×4

LHD/RHD

RHD

Dimension

Wheelbase (mm)

3300+1350

Chassis Dimensions (mm)

#N/A

Cargobox inner Dimensions (mm)

/

Weight

GVW (kg)

25000

Chassis kerb weight（kg）

90000

Cab

Body type

EST

Width(mm)

2490

Height

High roof

Number of people/number of seats

2

Engine

Brand

FOTON CUMMINS

Model

ISGe3-430

Type of fuel

Diesel

Displacement (L)

11800

Max power  (kw/hp/rpm)

316/430/1900

Max torque  (Nm/rpm)

2000/1000

Emission

Euro Ⅲ

Gearbox

Brand

ZF

Type

12TX2420TD（aluminium）

Gear position

12 MT

Brake

Brake type

Air brake

Auxiliary brake

ABS

Suspension

Suspension form

Leaf spring

Leaf spring number(front/rear)

9，12

Front/Rear axle

Rated load of front axle(T)

7.5T

Rated load of rear axle(T)

16T

Gear ratio

3.86

Tyre

Model

315/80R22.5 20PR guide  wheel/drive

Quantity

11

Frame

Dimensions

225/286×80×(8+5)

Fuel tank

Capacity (L)

450L

Material

Aluminum alloy

Additional configuration

Multi-media

MP3+radio+USB+no radar

A/C

Manual AC
