Brand

SHANTUI

Model

Shantui DH17-C3

Engine model

WP12

Machine working weight(kg)

19200kg

Ground pressure(kPa)

27

Rated power(Kw/rpm)

140/1900

Machine overall size(mm)

5262*4150*3240mm

Speed of advance(km/h)

F1:0-3.5/F2:0-6.2/F3:0-10.6

Reverse speed(km/h)

R1:0-4.5/R2:0-8.0/R3:0-13.1

Track center distance(mm)

2300

Track plate width (mm)

1100/950

Grounding length(mm)

2935

Fuel tank(L)

338

Working hydraulic tank(L)

70

Blade type

Straight tilting shovel

The depth of the shovel

485
