Brand

SHANTUI

Model

L58-C3 SG

(Sand version)

L58-C3 SG

Coal version

L58-C3 MH

Ore version

Engine model

WP10

WP10

WP10

Rated power(kW/rpm)

162/2000

162/2000

162/2000

Machine working weight(kg)

17200

18000

17650

Maximum dump clearance(mm)

3200/3450/3700

3210/3420

3215/3260

Dumping reach(mm)

1230/1200/1270

1395/1510

1125/1310

Machine overall size(mm)

8100*3030*3540

8460*3050*3540

8160*3075*3540

Maximum lifting force(kN)

≥185

≥185

≥185

Three items(s)

10.5

10.5

10.5

Speed of advance(km/h)

F1:0-13，F2:0-42

F1:0-13，F2:0-42

F1:0-13，F2:0-42

Reverse speed (km/h)

R:0-15

R:0-15

R:0-15

Wheelbase(mm)

3300

3300

3300

Fuel tank(L)

230

230

230

Rated bucket capacity (m³)

3

4

2.5

Rated loading capacity(t)

5

5

5
