Model

Unit

XE55D

Operating weight(without dozer blade)

Kg

5700

Bucket capacity

m³

0.2

Engine

Engine Model

/

4TNV94L-BVXG

No. of cylinders

/

4

Rated power/speed

kw/rpm

36.2/2200

Maximum torque/speed

N.m

210.6/1260

Displacement

L

3.054

Main performance

Travel speed(H/L)

km/h

4.2/2.2

Rotating speed

r/min

10

Gradeability

°

≤35

Ground pressure

kPa

31

Bucket digging force

kN

48.3

Arm digging force

kN

32.5

Maximum tractive force

kN

50.5

Rated flow of main pump

L/min

149.1

Main safety valve pressure

MPa

24

Travel system pressure

MPa

24

Swing system pressure

MPa

21

Pilot system pressure

MPa

3.5

Oil Capacity

Fuel tank capacity

L

110

Hydraulic tank capacity

L

77

Engine oil capacity

L

10

Appearance size

Overall length

mm

5860

Overall width

mm

1950

Overall height

mm

2585

Width of platform

mm

1780

Track length

mm

1920

Total width of chassis

mm

400

Track gauge

mm

1500

Counterweight clearance

mm

700

ground clearance

mm

385

Working range

Max. digging height

mm

5630

Max. dumping height

mm

3945

Max. digging depth

mm

3830

Max. vertical wall digging depth

mm

2680

Max. digging reach

mm

6130

Min. swing radius

mm

2460

Standard

Length of boom

mm

3000

Length of arm

mm

1600

Bucket capacity

m³

0.2
