Description

Unit

Parameter value

Operating weight

kg

33800

Bucket capacity

m³

1.4

Engine

Model

Engine

ISUZU AA-6HK1XQP

No. of cylinders

---

6

Output power

kW/ r/min

190.5/2000

torque/speed

N.m

872.8/1700

Displacement

L

7.79

Travel speed（H/L)

km/h

5.5/3.3

Main performance

Rotating speed

r/min

9.7

Gradeability

°

≤35

Ground pressure

kPa

66

Bucket digging force

kN

263

Arm digging force

kN

225

Maximum traction

kN

261

Hydraulic system

Main pump

--

2

Rated flow of main pump

L/min

2×280

Pressure of prime valve

MPa

34.3/37

Pressure of travel/swing system

MPa

34.3/26.5

Pressure of pilot system

MPa

3.9

Oil Capacity

Fuel tank capacity

L

630

Hydraulic tank capacity

L

350

Engine oil capacity

L

28

Overall size

mm

11388*3190*3515

Overall width of chassis

mm

3190

Wheel base of crawler

mm

3183

Crawler gauge

mm

2590

Clearance under counterweight

mm

1700

Working scope

Min. ground clearance

mm

495

Min. tail swing radius

mm

3570

Max. digging height

mm

10074

Max. dumping height/depth

mm

6898/6972

Max. digging depth at the range of level 8 feet

mm

6728

Max. digging reach

mm

10650

Min. swing radius

mm

4424
