Operating weight

Kg

15318

Bucket capacity

M³

0.58

Engine

Engine model

/

QSB4.5

Output power of engine

Kw/r/min

104/2000

Max.torque/engine

N.m

586

Displacement

L

4.5

Fuel tank capacity

L

250

Rated flow of main pump

L/min

2x160

Pressure of main safety valve

Mpa

31.4/34.3

performance parameter

Hydraulic tank capacity

L

135

Slewing speed

r/min

13.7

Digging capacity of tcuket

KN

60

Digging capacity of tcuket rod

KN

65

Min.turning radius

mm

6500

Travel speed

Km/h

-

Gradient capability

%

70

Working scope

A Total length

mm

6482

B Total width

mm

2552

C Total heigth

mm

3158

Counterweight ground clearance

mm

1230

Min.ground clearance

mm

359

Min.tail swing radius

mm

2300

Wheelbase

mm

2800

Track gauge

mm

1920

Total width of chassis

mm

2495

Distance between front axle and turning center

mm

1700

Hood height

mm

2430

The maximum digging depth of dozer

mm

112

Dozer (width / height)

mm

2495x564
