Model

Unit

Parameter

Operation weight

kg

21140

Bucket capacity

m³

0.86

Engine

Model

/

QSB6.7

Rated power

kw/rpm

129/2200

Max.torque

N.m

799

Displacement

L

6.7

Fuel tank

L

305

Main performance

Rated flow

L/min

220

Working pressure

Mpa

32

Hydraulic tank

L

202

Rotating speed

r/min

13

Bucket digging force

kN

115

Arm crowd force

kN

91

Min.swing radius

mm

6500

Travel speed

km/h

9.5/31

Grade ability

°

35°

Hydraulic system

/Pump/Pilot pump

/

Tow ram pumps

Apperance size

AOverall length

mm

9135

BOverall width

mm

2552

COverall height

mm

3370

DGround clearance of counterweight

mm

1250

EMin.ground clearance

mm

340

FTail swing radius

mm

2820

GWheel base of crawler

mm

2850

HTumbler distance

mm

1890

Iwidth of chassis

mm

2495

JDistance bttween the front axle and center rotation

mm

1550

KHeight of engine hood

mm

2542

LMax.dozer cutting depth

mm

145

MMax.dozer lifting height

mm

479

(/)Dozer(width/height)

mm

2467/566

Working scope

AMax.digging radius

mm

9613

BMax.ground digging distance

mm

9380

CMax.digging height

mm

10528

DMax.dumping height

mm

7530

EMax.digging depth

mm

5755

F8Digging depth at the range of level 8 feets

mm

5580

Standard configuration

Length of bucket arm

mm

2910

Bucket capacity

m³

0.86
