Description

Unit

XE17U

Operating weight

Kg

1795

Bucket capacity

m³

0.04

Engine

Model

/

D902

No. of cylinders

/

3

Output power

kw/rpm

11.8/2300

torque/speed

N.m

51.3/1800

Displacement

L

0.898

Main Performance

Travel speed(H/L)

km/h

3.1/2.1

Gradeability

°

30°

Ground pressure

kPa

28.5

Bucket digging force

kN

16

Arm croed force

kN

10

Maximum traction

kN

15.6

Oil Capacity

Fuel tank capacity

L

17

Hydraulic tank capacity

L

18

Engine oil capacity

L

3.8

Appearance size

Overall length

mm

3560

Overall width

mm

990/1240

Overall height

mm

2350

Width of platform

mm

990

Overall width of chassis

mm

990/1240

Width of crawler

mm

230

Track length on ground

mm

1270

Crawler gauge

mm

760/1010

Working Range

Max. digging height

mm

3475

Max. dumping height

mm

2415

Max. digging depth

mm

2290

Max. vertical wall digging depth

mm

1750

Max. digging reach

mm

3900

Min. swing radius

mm

1550
