Category

Item

Unit

Parameter

Outline Dimensions

Overall length

mm

11880

Overall width

mm

2550

Overall height

mm

3755

Wheel base

1st and 2nd Axles

mm

2950

2nd and 3rd Axles

mm

1650

Track

mm

2150

Weight

Dead weight in travel configuration

kg

36000

Axle load

1st axle

kg

12000

2nd axle

kg

12000

3rd axle

kg

12000

Power

/

/

/

MC11.36-50

Rated power of engine

kW/(r/min)

280/1900

268/1900

Travel

Travel speed

Max. travel speed

km/h

85

Min. stable travel speed

km/h

3

Min. turning diameter

m

14.2/(three axles steering)

Min. ground clearance

mm

330

Approach angle

°

19

Departure angle

°

21

Braking distance (at 30 km/h )

m

≤10

Max. grade ability

%

65

Oil consumption per 100 km

L

55
