Item

Unit

Parameter

Dimensions (length x width x height)

mm

14040 * 2790 * 3630

Total vehicle mass in travel configuration

kg

40330

Axle load

1st and 2nd axle

kg

16530

3rd and 4th axle

kg

23800

Engine model

-

W0615.334

Engine rated power/rpm

kW/(r/min)

247/2200

Max. output torque/rpm

N.m/(r/m1n)

1350/1100-1600

Max. travel speed

km/h

90

Min. turning diameter

m

24

Min. ground clearance

mm

250

App roach angle

°

18/10 (front protective device included)

Departure angle

°

13

Max. grade ability

%

38

Fuel consumption per 100 km

L

35

Max. total rated lifting capacity

t

50

Min rated working radius

m

3

Max. load moment

Base boom

kN.m

2009

Fully-extended boom

kN.m

933

Outrigger span

Longitudinal

m

6.1

Lateral

m

7.1

Hoist height

Base boom

m

11.2

Fully-extended boom

m

43.3

Boom length

Base boom

m

11.4

Fully-extended boom

m

43.5

Jib offset angle

°

0、15、 30

Boom raising time

s

≤40

Boom fully extending time

s

≤90

Hoistin Hoisting speed
(single line, 4th layer, no load)

Main winch

m/min

≥130

Auxiliary winch

m/min

≥130
