Maximum theoretical pumping capacity

180m³/h

Hydraulic system typ

open-type system

Maximum export pressure

8.5Mpa

Hydraulic system pressure

32Mpa

chassis

Sinotruk Sitrak

Driving axle

HC16*2, ratio 5.73

Engine brand

German Man

engine power

440/460Hp

wheel base

2100*4325*1370mm

Tires

12.00R20 ,12+1 pcs one spare tire

Bridge number

4

Total length * total width * total height

13800*2550*4000mm

Vehicle quality

44000kg

Maximum fabric height

57200mm

Maximum fabric depth

41000mm

Arm frame folding mode

RZ
