Condition : Brand New and Used
Brand : SUNWARD
Tonnes : 33 tons
Model : SWE335F
Backet Capacity :1.6-1.7m3
Product Parameters
| Features and specifications | ||
| Specifications | ||
| Operating weight | t | 32.5 |
| Bucket capacity | m3 | 1.6-1.7 |
| Engine | ||
| Make |
|
Isuzu |
| Model |
|
GH-6HK1 |
| Type |
|
Four-stroke, turbocharger, intercooled, direct injection |
| Power | kW/rpm | 212/2000 |
| Maximum torque | Nm/rpm | 1080/1500 |
| Displacement | L | 7.8 |
| Hydraulic system | ||
| Type of primary pump |
|
2 variable displacement piston pumps |
| Maximum flow of primary pump | L/min | 2X296 |
| System pressure | MPa | 31.4/34.3 |
| Type of pilot pump |
|
1 gear pump |
| Maximum flow of pilot pump | L/min | 30L |
| Pressure of pilot pump | MPa | 3.9 |
| Performance | ||
| Slewing speed | rpm | 11.42 |
| Traveling speed | km/h | 5.8/3.6 |
| Gradeability | o | 35 |
| Track width | mm | 600 |
| Ground pressure | kPa | 63.2 |
| Tank volume | ||
| Fueltankvolume | L | 520 |
| Hydraulic liquid tank volume | L | 400 |
