Product Parameter

Brand	SINOTRUK
Model	ZZ3257N3847A
Cabin	HW76 with single bunk with air conditioner
	Driving type:	LHD/RHD
Engine Model	WD615.47	336HP/371HP/420HP
	Emssion standard:	Euro 2
Gear box	CNHTC	Max torque:1900NM
	Model:	HW19710+HW50/10 speed+2 reverse
	Maximum speed (km/h)：	80
Axle(front/rear)
Front axle	VGD95
Tandem	HC16 double reduction hub redactor driving axle
Steering	ZF8118,LHD/RHD is optional with power assistance
Tyre	10+1 spare tyre with rim/12.00R20 radial tyre
	Front/Rear		10/12
Inside size of body(mm) : 5800*2300*1500,8mm(floor)*6mm(side),made of high intensity steel
Lifting type : Front lifter, hydraulic system
Overall dimension(mm) : 8545mm*2496mm*3350(Length+width+height)
Fuel tank	300/400L

Detail Image
