Brand

SINOTRUK

Model

ZZ3257V3647B1

Cabin

HW76 with single bunk with air conditioner

Engine Model

WP12.400E201

380HP/400HP/430HP

Emssion standard:

Euro 2

Gear box

CNHTC

Max torque:1900NM

Model:

HW19710+HW50/10 speed+2 reverse

Maximum speed (km/h)：

80

Axle(front/rear)

Front axle

VGD95  9.5T

Tandem

HC16  16T*2

Steering

Bosch,LHD/RHD is optional with power assistance

Tyre

315/80R22.5   12.00R22.5 10+1

Front/Rear

10/12

Bucket: 5400*2300*1400+150 movable plate mm, bottom 8 sides 6, general plate, field grid, middle top lift

Other: Main airbag seat,  high metal bumper, intercooler protection grille, oil bath air filter, reverse buzzer

Fuel tank

300L
